About Nippon Dry Chemicals

We offer a broad range of products like Sprinklers, Deluge & Alarm check valves and Cleam Agent cylinder assemblies. NDC UL LISTED EX28489, EX28490, EX28491, EX28492

NIPPON DRY CHEMICALS (FPP) is a distinguished leader in the chemical manufacturing industry, renowned for its unwavering commitment to quality and innovation. With a rich history spanning decades, the company has consistently delivered cutting-edge fire protection solutions that safeguard lives and assets worldwide. NIPPON DRY CHEMICALS (FPP) specializes in the production of high-performance dry chemical agents, meticulously engineered to combat diverse fire risks effectively.

Their products adhere to stringent international standards and have earned the trust of industries ranging from petrochemicals to aviation. NIPPON DRY CHEMICALS (FPP)’s dedication to research and development ensures that they remain at the forefront of fire safety technology, making them an indispensable partner for organizations seeking top-tier fire protection solutions.

We offer a broad range of products like Sprinklers, Deluge & Alarm check valves and Cleam Agent cylinder assemblies. NDC UL LISTED EX28489, EX28490, EX28491, EX28492.

Sprinkler

Sprinkler Flush Type

NDC automatic sprinklers NT2010 and NT2110 model series are designed for excellent impact resistance and sealing performance. When properly installed, only small portion of the sprinkler is visible below the ceiling.

NO.	Part	Material
1	Fuse Metal	Fusible Alloy
2	Heat Collector	Copper
3	Deflector	Stainless Steel
4	Valve Cap	Brass
5	Spring Seat	Ni-Be + PTFE

NO.	Part	Material
1	Fuse Metal	Fusible Alloy
2	Heat Collector	Copper
3	Deflector	Stainless Steel
4	Valve Cap	Brass
5	Spring Seat	Ni-Be + PTFE

Sprinkler Glass Bulb Type

NDC automatic sprinklers NT25 and NT26 model series incorporate decorative glass bulbs that operate at specific temperatures. These sprinklers are designed to discharge water in an umbrella-shaped spray pattern for use in various commercial application.

Alarm Check Valves

NDC NWAV-1 Alarm Check Valves are swing type waterflow alarm check valves intended for use in automatic wet-pipe fire sprinkler system. They activate the fire alarm via the pressure-actuated alarm switch when the water that is flowing into the system is equivalent to the discharge from one or more sprinklers. With the clapper having rubber facing that sits well with the seat ring, they also prevent water backflow when the water supply is stopped. They can also be fitted with a separately ordered retard chamber for installations subject to variable pressures. The retard chamber provides suitable time delay in order to eliminate potential false alarms due to surges or fluctuating water supply pressures. These Alarm Check Valves are intended to be installed in vertical orientation only.

Model Name	NWAV-1
Valve Size	2.5″ (DN65)	3″ (DN80)	4″ (DN100)	6″ (DN150)
Working Pressure	200psi (13.79bar)
Test Pressure	400psi (27.58bar)
Flange Type	ANSI B16.5 Class 150lbs
Direction	Vertical
Weight (Flanged ends)	13.1kg	14.7kg	16.7kg	28.2kg

Deluge Valve

The NDV-1 Deluge Valve features a unique pressure-operated tubular diaphragm configured axially inline with the water flow. The tubular diaphragm is a single-piece resilient and durable rubber part that has been shaped to create a control chamber with the valve body. Inlet water pressure supplied into the chamber pushes the diaphragm against the centrally-located seat, creating an airtight seal that prevents water flow.

Model Name	NDV-1
Valve Size	4″ (DN100)	6″ (DN150)
Working Pressure	250psi (17.24bar)
Test Pressure	500psi (34.5bar)
Connection Type	Flanged Ends (ANSI, KS/JIS) Grooved Ends (AWWA, KS/JIS)
Direction	Vertical Horizontal
Weight (Flanged ends)	31.0kg	47.3kg
